Sanitary Stainless Steel Welding Pneumatic Butterfly Valve with Actuator
Applications:
Butterfly valves, no matter manually or automatically, can be used in most fluid product applications in the food-processing, pharmaceutical and chemical industries.
Technical Parameters
| Standard |
3A,SMS,DIN,ISO,RJT,IDF |
| Product wetted steel parts |
AISI304/AISI316L |
Provided with material inspection report |
| Other steel parts |
AISI304 |
| Size |
1/2"~6",DN10~DN150 |
| Seal material |
EPDM/VMQ/FPM |
All seals material comply with FDA21CFR117.2600 |
| Working pressure |
≤10bar(145psi) |
| Supply pressure for air actuator |
5~8(0~116psi) |
| Working temperature |
EPDM:-14~248ºF(-10~120ºC) |
| VMQ:-58~356ºF(-50~180ºC) |
| FPM:22~446ºF(-30~230ºC) |
| Other materials are avaible upon request |
| Sterilization temperature |
302ºF(150ºC,max 20min) |
| Outside surface treatment |
Ra16~32uin(o.4~0.8um) |
| Inside surface treatment |
Ra32~64uin(o.8~1.6um) |
| Connetion ends |
butt-weld,clamped ends,male ends, flange ends |
| Pneumatic head |
Normally closed(NC)-Air to open,spring to close |
| Normally open(NO)-Air to close,spring to open |
| Air to air(AA)-Air to open,air to close |
We also supply other types of valves,such pneumatic butterfly valves,actuated butterfly valves,pneumatic butterfly valves with control head,and ect.
